35kHz Ultrasonic Transducer 2535-4D For Ultrasonic Welding
The transducer decide the property of the machine. We can supply transducer , also transducer with house and booster.
Send Inquiry
Product Introduction
35kHz Ultrasonic Transducer 2535-4D For Ultrasonic Welding
Description :
Transducer is the core part of the ultrasonic whole machine, Ceramic chip is the key part for transducer , so we insist use the best ceramic chip.
Specification :
| Frequency | 35kHz |
| Max Power | 500watt |
| Ceramic Diameter | 25 mm |
| Qty of Ceramic | 4 pcs |
| Connect Screw | M8 |
| Capacitance | 3.9~4.3nF |
| Max Amplitude | 6um |
Advantage :
Imported ceramic chip
Titanium , aluminum , steel optional
One years warranty
Workshop :
CE :
Shipping :
Payment allowance :
Hot Tags: 35khz ultrasonic transducer 2535-4d for ultrasonic welding, China, manufacturers, suppliers, factory
