Ultrasonic Welding Vibrator With Purple Booster 20Khz

Ultrasonic Welding Vibrator with Purple Booster 20Khz

Description:

The vibrator consists of an important component ultrasonic transducer and a horn. Ultrasonic transducers use the piezoelectric effect of piezoelectric ceramics to convert electrical energy and mechanical energy (sonic vibration). The main function of the horn is to amplify the mass displacement or velocity of the mechanical vibration, and concentrate the ultrasonic energy on a small area, that is, the energy.

Detailed Product Description:

Model: Ultrasonic Vibrator with Purple Booster

Frequency: 20 khz

Output power: 2000 watt - 4000 watt

Joint bolt: 1/2-20UNF

Ceramic disc Diameter: 50 mm

Quantity of Ceramic discs: 6 pcs

Capacitance: Different item No., with different capacitance

Amplitude: 20 um

Application: For Welding

Main Features:

1. High performance: high conversion efficiency and excellent quality;

2. Large amplitude and superior performance;

3. Heat resistance: The imported piezoelectric ceramic material has good heat resistance, can expand the use temperature range, and has high Q value, small resonance impedance and small heat generation;

4. The appearance of the product is neat, no rust, no obvious depressions and scratches.

Applications:

Household appliances, gardening supplies, decoration, merchandise, automotive parts, electronics, stationery.

If you need to disassemble and install the transducer and booster in the ultrasonic vibrator, you could watch the following video for help.
