Ultrasonic Welding Transducer With 40khz 4um Amplitude

Ultrasonic Welding Transducer with 40khz 4um amplitude

Description

Ultrasound creates acoustic cavitation, which produces violently imploding vacuum bubbles, causing shock waves, microjet and strong shear forces as well as extreme local temperatures (~5,000 K) and pressures (~1,000 atm). These extreme conditions result in exceptionally efficient mixing, yielding nanoemulsions with very small droplet sizes and enormous contact areas between all components.

Specification

Model	HS-2040-2D
Frequency	40khz
Output power	300watt
Joint bolt	M8
Ceramic disc   Diameter	20 mm
Quantity of   Ceramic discs	2 pcs
Capacitance	1.1-1.3nf
Amplitude	4um
Application	Sonochemistry

Applications

Ultrasonic Converters and Ultrasonic Transducers are one in the same. There is one Ultrasonic OEM, Dukane Corporation, that uses the term Transducer. All of the other ultrasonic OEM manufactures such as Branson, Sonics and Materials, Rinco, Telesonics and Herrmann refer to these as Converters or Konverters.

Competitive Advantage

1.Custom System Designs and Consulting:

2.Active Ultrasonic provides consulting services and custom reactor designs.

3.High Power Probe Sonicator

4.Once assembled, the transducers are aged before testing and final assembly. The properties of piezoelectric materials can change with time and pressure, so a bit of time on the shelf prior to testing will identify nonconforming material.
