Ultrasonic Transducer Replacement Converter Branson CJ20
Ultrasonic Transducer Replacement Converter Branson CJ20
Specification:
Model | HSBCJ20 |
Frequency | 20 khz |
Output power | 3000 watt |
Joint bolt | 1/2-20 UNF |
Ceramic disc Diameter | 50 mm |
Quantity of Ceramic discs | 6 pcs |
Capacitance | 19-21 nf |
Amplitude | 20 um |
Application | welding machine |
Introduction:
Ultrasonic transducer is a kind of energy conversion device. Its function is to convert the input electric power into mechanical power (ultrasound) and then transmit it out, while it consumes a small part of the power (less than 10%). Therefore, the most important consideration for ultrasonic transducers is the matching with the input and output ends, followed by mechanical installation and matching dimensions.
