Piezoelectric Ceramics materials are categorized as functional ceramics. In sensors they make it possible to convert forces, pressures and accelerations into electrical signals, and in sonic and ultrasonic transducers and actuators they convert electric voltages into vibrations or deformations.

Send Inquiry

Product Introduction

Ring Piezoelectric Element Piezoelectric Ultrasonic Ceramic Disc

Specification

Size	50206	603010
MOQ	90Pcs	32Pcs
Application	20kHz transducer	15kHz transducer
Color	Yellow	Yellow

Description

Piezoelectric ceramics are mainly used in the manufacture of ultrasonic transducers, Piezoelectric ceramic elements are widely used in various fields electro acoustics, ultrasonic, communications, test and measurements, automatic control, medical ultrasound, ignition, etc.

Advantage

1. High efficiency: high mechanical parameter Q, the transduction efficient between electricity and sound above 95%.

2. High amplitude: the transducer strength is improved by fixing the high speed vibrator directly on the base of washing groove with bolt. Compare with a magnetic expansion vibrator, its amplitude can be improved above 50%.

3. Good heat resistance: a large range of working temperature, low resonance impedance and heat productivity.

4. Good construction: fastened by bolt, easy for assembling, high reliability.

Detailed Image
