High Quantity 20khz Ultrasonic Welding System Used Analog Generator And Transducer With Horn

High Quantity 20khz Ultrasonic Welding System Used Analog Generator And Transducer With Horn

Description:

The transducer is assembled and debugged by a teacher with more than 30 years of installation experience, and the assembly process is excellent, which is the standard of the ultrasonic industry;The generator is the analog generator, the horn is the normal horn 110*20mm

Specification:

Theory:Ultrasonic Sensor

Product Name:Ultrasonic Welding Transducer

Horn size: 110*20cm

Weight:20kg

Size:45*38*25cm

Product name:HS-W20

Frequency: 20khz

Power：2000w

advantage:

1. The consistency of the parameters of the transducer is very high, which provides convenience for customers to match the ultrasonic power supply;

2. The impedance is very small, less than 7 ohms, greatly reducing the heat and loss of the transducer;

3. The output amplitude is large, greater than or equal to 10 microns;

4. The energy conversion rate is greater than 95%;
