Ultrasonic Sound Intensity and Frequency Measuring

Specifications Ultrasonic Power Measuring Meter: Measuring ultrasonic power in the liquid. The ultrasonic strength in the liquid sound field is the most important index of the ultrasonic system. There is a direct influence for the cleaning effect of cleaning machine and work efficiency of the...

Chat Now
Product Details

Ultrasonic Sound Intensity and Frequency Measuring


Ultrasonic Power Measuring Meter: Measuring ultrasonic power in the liquid. The ultrasonic strength in the liquid sound field is the most important index of the ultrasonic system. There is a direct influence for the cleaning effect of cleaning machine and work efficiency of the ultrasonic processor. Ultrasonic power measuring instrument can measure the strength of the sound field whenever possible,quickly and easily. Moreover, it directly indicates the sound numerical value.
According to the different using fields, the ultrasonic power measuring instrument can be made into portable and monitoring types.


Instrument Parameters

Model

HS-200I

Sound Intensity Range (W/cm2)

0-2.54

Sound Intensity Resolution (W/cm2)

0.01

Frequency of Liquid Environment

19.9KHz-99.9KHz

Temperature Range

0-75℃

Standby Power Consumption

10-5W

Display

3.2 Inch TFT(320*240)

Power Supply

Two 3.7V Rechargeable Lithium Batteries

Operation Style

Film Button

Size (mm)

216(L)*100(W)*34(D)

Weight (g)

354

Input Power

4.2-40(Vpp)


Application:
Ultrasonic sound intensity measuring instrument is to measure the ultrasonic cleaning tank in the ultrasonic intensity (sound pressure) of the measuring instruments. It can help you complete the following tasks:
(1) measure the cleaning effect of industrial parts
(2) measure the performance of the cleaning tank
(3) control the energy level of the cleaning tank (frequency)
(4) Evaluate the consistency of the cleaning tank and guide the design of the cleaning tank
(5) Mapping changes in ultrasonic energy in cleaning tanks

Workshop:


CE Certification:




Packing&Shipping

Shipping Port:Shanghai

Shipping Term:By express,by air,by ocean and so on.

Leading Time:Quick production leading time and fast delivery.



Payment:




Quality control:

 3 times old test to confirm the products is well quality.

20 technician work together , and learn together , to improve our products.

48 hours working time to test the stability of our product before sending out.
